Opaque Curtains - 18oz, 22oz

• Vinyl coated polyester reinforced with scrim
• NFPA fire retardant, CFM fire retardant
• 18oz and 22oz are outdoor rated
• Finished edges for clean crisp appearance
• Double or triple hems used where needed for longevity
• Ideal for temperatures going as low as -20° F to 160° F
• All colors are the same price
• 18 oz = .020″ thick, 2.0 oz. per square foot
• 22 oz = .024″ thick, 2.44 oz. per square foot

Clear Curtains - 20mil and 40mil

• Clear double polished PVC
• NFPA fire retardant, CFM fire retardant
• Outdoor rated
• Finished edges for clean crisp appearance
• Double or triple hems used where needed for longevity
• Ideal for temperatures going as low as 10° F to 140° F
• 20 mil = 20mil thick, 1.98 oz. per square foot
• 40 mil = 40mil thick, 3.95 oz. per square foot

Chain Weight Bottoms

If you have a slight breeze or are power washing near the curtain then we can add a galvanized 3/16" chain weight to the bottom of the curtain.

Floor Anchor Straps

Velcro straps hold your curtain in place if wind is present or a more secure curtain is required. These anchors feature Velcro straps which loop through a D-ring which is anchored into the cement floor. Typically spaced every 4'.

Floor Sweeps

A floor sweep seals the open area between the curtain and the floor. It attaches to the main curtain by Velcro. They are 6″ tall and as long as the entire length of the curtain. These are ideal for controlling dust, fumes, odors and other undesirable elements. They can also be replaced in the future should the friction from the floor wear them out.

Magnet Seals

Seal magnets are an idea to attach curtains to each other or adjacent steel walls and beams. Best utilized in dusty areas that would clog up Velcro.

Velcro Seals

You can choose to have Velcro installed along the perimeter of the divider which will allow you to combine multiple curtains into one larger curtain. You can also attach self adhesive Velcro to fixed objects such as walls for a more complete seal. Great for dust control and temperature control.

Wind Mesh Panels

Reduces stress on the curtain by allowing some wind through the curtain. Ideal for very windy applications and large curtains. Spaced approximately every 6'.

• Less expensive than rigid walls
• Can be taken down quickly when not needed
• Can be stored when not needed
• Divide areas quickly
• Quick to roll out of way when not in use
• Easy to clean as a result of the slick surface of Vinyl
• Keeps the elements out and makes your area comfortable
• Lifetime warranty on all hardware and 1 year manufacture warranty on curtains

Common Layouts

ALCO can supply just about any layout you can think of. Below are some common layouts. They can be single sided, double-sided, triple sided, four-sided or multiple straights to create complete enclosures. You simply inform ALCO about your desired design and we will have it fabricated exactly as you need it. For customized layouts, simply sketch your design and upload it using our online RFQ form. See button below.

Vision Panel Options
